HandySCAN| Silver Series

Featuring dynamic referencing, both the scanner and part can move freely during scanning, and an accurate and high-quality scan can still be obtained.

Using triangulation on optical reflectors to determine its relative position to the part, this handheld 3D scanner is a stand-alone device that does not require a tripod or any external tracking device to operate. Compact enough to fit into a small suitcase, it can be brought anywhere and used in any environmental condition without affecting its performance.

With its user-friendly interface and ergonomic design, this 3D measurement solution is easy to use and has a short learning curve regardless of the user’s experience or expertise level. Its versatility enables users to scan various objects no matter the part size, complexity, material, or color—all with the same device.

TOP FEATURES

ACCURACY UP TO

.030 mm

PROVEN AND TRUSTED SOLUTIONS

BEST PRICE/PERFORMANCE OPTION

TRAINING AND SUPPORT

ULTIMATE 3D SCANNING SOLUTIONS FOR INNOVATORS

3D SCANNING & REVERSE ENGINEERING

The ultimate goal of reverse engineering is generally to create a 3D CAD (Computer Aided Design) model for use in the customer’s design system.  Using software from GeomagicPolyWorksSOLIDWORKSVXelementsANSYS and Polyga, we are able to deliver several different types of models which we generate from 3D scanned data.

COMPUTER-AIDED INSPECTION & ANALYSIS

Computer Aided Inspection software allows users to process 3D scan data and determine that all part specifications have been met. By providing graphical comparisons between CAD models and parts that can be used for first article inspection, alignment, analysis or wear, validating tooling, and both 2D & 3D geometric dimensioning and tolerancing (GD&T).

With computer aided inspection, part production is faster and the parts are much more accurate by eliminating manufacturing errors in advance.

PROFESSIONAL TRAINING: OPERATING 3D SCANNERS

NeoMetrix offers professional training for all 3D scanning, 3D printing and software products that we represent, including 3D Systems & Markforged 3D Printers, Creaform & Steinbichler 3D Scanners, as well as Geomagic & Discovery SpaceClaim Software. **Included with the original sale of a system, however, we are also to provide add-on training for new employees.

In addition to basic operation training, we can also provide application specific training designed to meet your organization’s unique needs!

Speak With an Expert!

Fill out our quick contact form or call us today- (888) 696-7226

COMPATIBLE SOFTWARE:
 + MORE

Seeking 3D Scanning solutions or services that will get your company or projects ahead of the pack?

Our experts will guide you through the benefits of using the HandySCAN 3D| SILVER Series in your application.
Speak with an Expert

TECH SPECS

HandySCAN| Silver Series

Accuracy: Up to 0.030 mm (0.0012 in)

Volumetric Accuracy: 0.020 mm + 0.060 mm/m
(0.0008 in + 0.0007 in/ft)

Volumetric Accuracy with MaxSHot NEXT Elite: 0.020 mm + 0.015 mm/m
(0.0008 in + 0.00018 in/ft)

Mesurement Resolution: 0.050 mm (0.0019 in)

Mesh Resolution: 0.200 mm (0.0078 in)

Measurement Rate: 480,000 measurements/s

Light Source: 7 red laser crosses (+ 1 extra line)

Laser Class: 2M (eye safe)

Scanning Area: 275 x 250 mm (10.8 x 9.8 in)

Stand-off Distance: 300 mm (11.8 in)

Depth of Field: 250 mm (9.8 in)

Part Size Range: 0.1–4 m (0.3–13 ft)

Software:  VXelements

 Output Formats: .dae, .fbx, .ma, .obj, .ply, .stl, .txt, .wrl, .x3d, .x3dz, .zpr, .3mf

Compatible Software: 3D Systems (Geomagic® Solutions), InnovMetric Software (PolyWorks), Metrologic Group (Metrolog X4),
New River Kinematics (Spatial Analyzer), Verisurf, Dassault Systèmes (CATIA V5, SOLIDWORKS), PTC (Creo),
Siemens (NX, Solid Edge), Autodesk (Inventor, PowerINSPECT)

Weight: 0.85 kg (1.9 lb)

Dimensions: 77 x 122 x 294 mm (3.0 x 4.8 x 11.6 in)

Connection Standard: 1 X USB 3.0

Operating Temp Range: 5–40°C (41–104°F)

Operating Humity Range: 10–90%

Certifications: EC Compliance (Electromagnetic Compatibility Directive, Low Voltage Directive),
compatible with rechargeable batteries (when applicable), IP50, WEEE
